Non-pressure trap P33-200
Série 33

Non-pressure trap P33-200

P33-200 / P33-300 / P33-400 / P33-500 / P33-600
Home Hatches Pressureless hatchesNon-pressure trap P33-200
Non-pressure hatches P33-200 / P33-300 / P33-400 / P33-500 / P33-600
Request a quote Standards and specifications Normes et spécifications
Finishes On steel or carbon
  • Manufacturing crude without coating
On stainless steel
  • BURNISHING: Rolled sheets and flats, presence of tool marks, unstripped welds.
  • MICROBLES: Satin matte appearance.
  • ELECTROPOLISHING WITH Ra (µ): on request from < 1.6 to > 0.4.
Frame
  • Stainless steel 2B plate 1.4301 / 1.4307 or 1.4404, height 80 mm, thickness 2 mm, usable passage with tolerance of /- 2 mm.
  • Standard finish: exposed vertical weld, electropolished
Wicket door
  • Sheet 2B 1.5 mm (200, 300, 400), 2 mm (500, 600) in stainless steel 1.4301 / 1.4307 and 1.4404, electropolished.
Component parts
  • Stainless steel 1.4301 or 1.4307
  • Technopolymer handwheel with brass insert
  • Stainless steel handwheel or lever in 1.4401, 1.4404, 1.4305, 1.4301 or 1.4307 with or without bronze insert according to model to be seen with the sales department

Technical data

DN Porte Frame Space requirement Number of clamps Unit weight
in kg
CALCULATION PRESSURE (non-FEP gasket)
CODAP IN BAR at 150°
(To be limited according to gasket material used)
Pmax
Maximum working pressure
at room temperature (Bar) non-FEP joint.
Door not submitted.
Vacuum
Vacuum pressure
Absolute value in BAR
(non-FEP joint )
Seals
A C E B D
Dim hors tout
Operating pressure 150°C Test pressure 20°C ASME 2007 in BAR at 150° without 'u' stamp
P33-2002008021963004NANA0,3NAsticked
P33-3003008021704005NANA0,2NAclipped
P33-4004008021704958NANA0,05NAclipped
P33-50050080218459510NANA0,05NAclipped
P33-60060080222670512NANA0,05NAclipped
