Série 31
Non-pressure Aseptic Traps P31-080
P31-080 / P31-081
Finishes
Frame
Wicket door
Component parts
- Manufacturing crude without coating
- BURNISHING: Rolled sheets and flats, presence of tool marks, unstripped welds.
- MICROBLES: Satin matte appearance.
- ELECTROPOLISHING WITH Ra (µ): on request from < 1.6 to > 0.4.
- Stainless steel sheet 1.4301 / 1.4307 or 1.4404, height 100 mm, thickness 3 mm, usable passage with tolerance of /- 1 mm.
- Standard finish: electropolished
- Thickened embossed plate 3 mm in stainless steel 1.4301 / 1.4307 and 1.4404, electropolished.
- Stainless steel 1.4301 or 1.4307.
- P31-080: brass curved handle / P31-081: technopolymer with brass insert
Technical data
| DN Porte | Frame | Space requirement | Number of clamps | Unit weight in kg |
CALCULATION PRESSURE (non-FEP gasket) CODAP IN BAR at 150° (To be limited according to gasket material used) |
Pmax Maximum working pressure at room temperature (Bar) non-FEP joint. Door not submitted. |
Vacuum Absolute value in BAR (non-FEP joint ) |
Seals | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | C | E | B | D Dim hors tout |
Operating pressure 150°C | Test pressure 20°C | ASME 2007 in BAR at 150° without 'u' stamp | ||||||
| P31-080 | 790 | 100 | 3 | 170 | 884 | 8 | 25 | NA | NA | 0,1 | NA | saddle | |
| P31-081 | 790 | 100 | 3 | 170 | 928 | 8 | 25 | NA | NA | 0,1 | NA | saddle | |
