Série 22
Exterior Round Pressure Doors P22-233
P22-233 / P22-250 / P22-300 / P22-333 / P22-354 / P22-433 / P22-444 / P22-446 / P22-449
Finishes
Frame
Wicket door
Component parts
- Manufacturing crude without coating
- BRUT: Rolled sheets and flats, presence of tool marks, unstripped welds.
- MICROBLES: Matte satin appearance. ELECTROPOLISHED.
- POLISHING WITH Ra (µ) : on request from < 1.6 to > 0.4.
- Hot rolled plate in stainless steel 1.4301 / 1.4307 or 1.4404, height 100 mm, thickness 12 mm, useful passage with tolerance of /- 2 mm.
- Finish: internal / external machining
- 6mm thick spun sheet in stainless steel 1.4404, mounted on machined stiffener frame Ra interior <=1µ electropolished.
- Stainless steel clevis and "U" clamp 1.4308.
- Stainless steel handle in 1.4404 with or without bronze insert according to model to see with the sales department.
Technical data
| DN Porte | Frame | Space requirement | Number of clamps | Unit weight in kg |
CALCULATION PRESSURE (non-FEP gasket) CODAP IN BAR at 150° (To be limited according to gasket material used) |
Pmax Maximum working pressure at room temperature (Bar) non-FEP joint. Door not submitted. |
Vacuum Absolute value in BAR (non-FEP joint ) |
Seals | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| A | C | E | B | D Dim hors tout |
Operating pressure 150°C | Test pressure 20°C | ASME 2007 in BAR at 150° without 'u' stamp | ||||||
| P22-233 | 204 | 100 | 12 | 220 | 371 | 3 | 16 | 8,0 | 15 | 12,0 | 0,1 | clipped | |
| P22-250 | 250 | 100 | 12 | 220 | 424 | 3 | 19 | 5,0 | 12 | 10,0 | 0,1 | clipped | |
| P22-300 | 300 | 100 | 12 | 220 | 471 | 4 | 21 | 7,0 | 11,5 | 10,0 | 0,1 | clipped | |
| P22-333 | 354 | 100 | 12 | 223 | 528 | 3 | 23 | 3,0 | 5 | 5,0 | 0,1 | clipped | |
| P22-354 | 354 | 100 | 12 | 223 | 528 | 4 | 25 | 5,6 | 11 | 8,0 | 0,1 | clipped | |
| P22-433 | 400 | 100 | 12 | 241 | 583 | 4 | 33 | 3,0 | 5,0 | 3,0 | 5,0 | 0,1 | clipped |
| P22-444 | 400 | 100 | 12 | 241 | 583 | 5 | 34 | 4,3 | 8,0 | 4,3 | 6,0 | 0,1 | clipped |
| P22-446 | 400 | 100 | 12 | 241 | 583 | 6 | 35 | 5,0 | 10,0 | 5,0 | 8,0 | 0,1 | clipped |
| P22-449 | 400 | 100 | 12 | 241 | 583 | 9 | 40 | 8,5 | 14,0 | 8,5 | 12,0 | 0,1 | clipped |
